High-Pressure Globe Valve
Introduction of High-Pressure Globe Valve
The design and construction of a high-pressure globe valve are ideal for both high-pressure and high-temperature systems. It is made from a range of materials, including stainless steel, cast steel, alloy steel, and carbon steel. It can be operated either manually through a lever or gear or automatically through an electric or pneumatic actuator.
This globe valve usually has a nominal pressure between Class 150 and Class 2500 and a working temperature between -29°C and 560°C. It is excellent for throttling and shut-off services for power, oil and gas, offshore, petrochemical, and other applications with severe working conditions. XHVAL provides more well-performanced globe valves for your different applications.
Specifications
| Materials | Stainless steel, cast steel, alloy steel, and carbon steel |
|---|---|
| Pressure | Class 150 and Class 2500 |
| Design and Manufacturing Standards | BS 1873 |
| Face to Face Standards | ASME B16.10 |
| Flange Dimension Standards | ASME B 16.5, ASME B16.47 |
| Pressure Test Standards | API598 |
| Fire Safety Test Standards | API607 |
| Quality/Product Certifications | ISO9001, ISO14001, ISO18001 |
| Fugitive Emissions | ISO 15848-1, API 622 |
| NACE | NACE MR 0103 NACE MR 0175 |
| Valve operator options | Handwhel, Worm Gear, Electric actuator, Pneumatic actuator, Hydraulic Actuator. |
| Shutoff Class | API 598 (Zero Leakage), |
| Bore | Full Bore |
| Process Connection Types | RF, RTJ, BW |
