T type strainer
T Type Strainer
Tee type strainer dimensions for Class 150LB，300LB,600LB
Introduction of T Type Strainer
Manufacturer and supplier of ANSI TEE TYPE STRAINER, carbon steel (WPB ) or Stainless steel materials, pressure rating ansi class 150lbs, both flange ends and butt weld ends (bw ends), bolted cover with drain plug.
Specifications
| Valve Size | 2″~14″ |
|---|---|
| Pressure Class | 150LB~600LB |
| Materials | WCB, WCC, CF8, CF3, CF3M, CF8M, |
| Design and Manufacturing Standards | ASME B16.34 |
| Face to Face Standards | ASME B16.10 |
| Flange Dimension Standards | ASME B 16.5, ASME B16.47 |
| Pressure Test Standards | API598 |
| Fire Safety Test Standards | API 607 |
| Quality/Product Certifications | ISO9001, ISO14001, ISO18001 |
| Fugitive Emissions | – |
| NACE | NACE MR 0103 NACE MR 0175 |
| Valve operator options | – |
| Shutoff Class | API 598 (Zero Leakage), API 6D |
| Bore | FULL BORE |
| Process Connection Types | RF, BW |
