2 Piece Cast Steel Floating Ball Valve
The XHVAL 2 Piece Cast Steel Floating Ball Valve uses a two-piece body and floating-ball construction for industrial isolation duties. Published configurations cover NPS 1–10 and ASME Class 150–600, with material, bore, end connection, operator, testing and document requirements reviewed against the application and RFQ.
- Two-piece body with floating-ball construction
- Published size range: NPS 1–10
- Published pressure range: ASME Class 150–600
- Full-bore and reduced-bore configurations listed
- Manual, gear and actuated operation options can be reviewed
Two-piece construction for industrial isolation
In a floating ball valve, the ball is supported by the seats and can move slightly in response to line pressure. The resulting seat load is one of the factors considered when reviewing sealing, operating torque and service suitability. The two-piece body provides a separate body and end connection section, creating a compact construction that can be specified with different bore, material, connection and operator requirements.
This valve can be considered for liquid or gas isolation duties when the selected body, trim, seats and seals are compatible with the process medium and operating conditions. Full-bore and reduced-bore routes are listed, while flanged, welded and threaded connection options should be confirmed against the applicable piping specification.
Product suitability cannot be determined from valve size and pressure class alone. Temperature, media chemistry, solids content, flow direction, cycling frequency, required shutoff performance, actuation and document scope can all affect the final configuration. XHVAL reviews the submitted service conditions and purchasing requirements before confirming the quotation and order scope.
Published product configuration range
Use the table to prepare an enquiry. The applicable combination of size, pressure class, materials, standards, connections and operation must be confirmed for the selected valve.
| Specification | Published product information |
|---|---|
| Valve size | NPS 1–10 |
| Pressure class | ASME Class 150–600 |
| Published material options | WCB, WCC, A105, LF2, WC6, WC9, CF8, CF3, CF3M, CF8M, F316, 4A and 5A. Confirm material grade and body construction for the selected configuration. |
| Design and manufacturing references | API 6D, API 608, ASME B16.34 and ISO 17292, as applicable to the confirmed product and order scope. |
| Face-to-face reference | ASME B16.10; confirm the required standard and dimensions in the RFQ. |
| End connection options | Socket weld (SW), threaded (NPT), butt weld (BW), raised face flange (RF) and ring-type joint flange (RTJ), subject to configuration review. |
| Pressure testing references | API 598 and API 6D, when specified and applicable to the selected valve. |
| Fire testing references | API 6FA and API 607 requirements can be reviewed when stated in the enquiry. |
| Fugitive-emissions references | ISO 15848-1 and API 622 requirements can be reviewed against the selected construction and order documents. |
| Sour-service reference | NACE MR0175 / ISO 15156 requirements should be stated with the material and service conditions. |
| Operation options | Manual handle, worm gear, electric actuator, pneumatic actuator or hydraulic actuator; actuator sizing requires operating data. |
| Bore options | Full bore or reduced bore |
| Documentation | State required drawings, material records, inspection and test records, certificates, standards and editions in the RFQ. |
Compare other ball valve constructions
Review related floating, trunnion-mounted and service-specific products, then send the operating conditions for final configuration review.
